System diagram
Heating
-FL3
-QM42
-QM12
-CM2
Lables according to IEC 61346-2
-QM34
-XL15
-BT1
-QM31
-QM32
-HQ1
F1245
-EB100
-FL2
-CM1
-EP12
Function
The heat pump prioritises hot water charging. The circulation pump GP1 runs at a set speed.
TIP
More system principles are on www.nibe.eu.
Refer to the Installer manual for description of
possible docking alternatives.
15Chapter 3 | System descriptionF1245
