Nibe F1245 Service Manual

Installation requirements
Heating medium side
1x230 V
12 kW10 kW8 kW5 kW
4BarMax system pressure
18015012075lMin recommended volume heating system*
0.190.160.130.08l/sMin flow**
0.270.220.180.10l/sNominal flow
0.350.290.230.13l/sMax recommended flow
58646468kPaMax external available pressure at nom flow***
See diagram page 76.°CMin/max temperature
3x230 V
12 kW10 kW8 kW6 kW
4BarMax system pressure
18015012090lMin recommended volume heating system*
0.190.160.130.10l/sMin flow**
0.270.220.180.13l/sNominal flow
0.350.290.230.17l/sMax recommended flow
58646467kPaMax external available pressure at nom flow***
See diagram page 76.°CMin/max temperature
3x400 V
12 kW10 kW8 kW6 kW5 kW
4BarMax system pressure
1801501209075lMin recommended volume heating system*
0.190.160.130.100.08l/sMin flow**
0.270.220.180.130.10l/sNominal flow
0.350.290.230.170.13l/sMax recommended flow
5864646768kPaMax external available pressure at nom flow***
See diagram page 76.°CMin/max temperature
* min volume refers to circulating flow
** overflow valve must be used if min flow cannot be guaranteed
*** external circulation pump must be used when the pressure drop in the system is greater than the available ex-
ternal pressure. In such cases, a bypass line with non-return valve must be installed.
F1245Chapter 3 | System description16

Nibe F1245 Specifications

General

Refrigerant	R410A
Control System	NIBE SMO 40
Dimensions (HxWxD)	1800 x 600 x 620 mm
Energy Efficiency Class Heating 35°C	A++
Energy Efficiency Class Heating 55°C	A++
Heating Capacity	5-12 kW
COP Heating	4.5
Integrated Hot Water Tank	180 liters
Power Input Heating	1.0 - 3.0 kW
