60 NIBE F1330
Control
Menu 5.4.4 Level monitor [U]
Select here if an external brine pressostat, level sensor or
flow sensor is connected to the “EBV card”.
Can be set to On (NC), On (NO) or Off. The factory setting
is Off.
Menu 5.4.5 Start to start time [U]
The shortest time from start to start of the same compres-
sor is set here. Can be set between 20 and 60 minutes.
The factory setting is 20 minutes.
Menu 5.4.6 Oper. mode brinepump [U]
The operating mode for the brine pump is set here.
Selectable options are:
Intermittent: The brine pump starts 20 seconds before
and stops 20 seconds after the compressor.
Continuous: Continuous operation.
10 days cont: Continuous operation for 10 days.
The pump then switches to intermittent operation.
The factory setting is Intermittent.
Menu 5.4.7 Oper.mode heat pump A [U]
The operating mode for the heating medium pump A
(VBP-A) is set here. Selectable options are:
Intermittent: The heating medium pump starts 20 sec-
onds before and stops 20 seconds after the compressor.
Continuous: Continuous operation.
Economy: The pump is operational a specific time per
period (see menu 6.1.2 and 6.1.3), and together with the
compressor.
The factory setting is Intermittent.
Menu 5.4.8 Oper.mode heat pump B [U]
The operating mode for the heating medium pump B
(VBP-B) is set here. Selectable options are:
Intermittent: The heating medium pump starts 20 sec-
onds before and stops 20 seconds after the compressor.
Continuous: Continuous operation.
Economy: The pump is operational a specific time per
period (see menu 6.1.2 and 6.1.3), and together with the
compressor.
The factory setting is Intermittent.
Menu 5.4.9 Quickstart of compr. [U]
Select Yes in order to reduce the pressure-compensating
time to 0 and in doing so permit a quick start.
NOTE! The setting returns to No as soon as the heat pump
has implemented the action.
Menu 5.4.10 Factory pre-set [U]
The heat pump can be reset to the factory settings here.
Normal: Factory settings on all settings except the system
settings (menu 0.x and 9.x) and operating statistics.
Expanded: Factory settings on all settings except operat-
ing statistics.
NOTE! The setting returns to No as soon as the heat pump
has implemented the action.
Menu 5.4.11 Reset alarm [U]
Resetting/acknowledging an alarm on F1330.
Menu 5.4.12 Pool heating compr. A [U]
The menu is only displayed when pool is selected as “On”
in menu 9.1.5
If it is “On”, compr. A in the heat pump that is selected in
menu 5.1 is permitted to carry out pool heating.
Menu 5.4.13 Pool heating compr. B [U]
The menu is only displayed when pool is selected as “On”
in menu 9.1.5
If it is “On”, compr. B in the heat pump that is selected in
menu 5.1 is permitted to carry out pool heating.
Menu 5.4.14 Return [U]
Pressing the enter button returns you to menu 5.4.0.
Menu 5.5.0 Sensor calibration [S]
Sensors are calibrated here using the sub-menus. All (Menu
5.5.1 - 5.5.9) are adjustable between -5 and +5 °C in incre-
ments of 0.1 °C. Factory setting on all is 0 °C.
Menu 5.5.1 Heating return A [S]
Menu 5.5.2 Heating return B [S]
Menu 5.5.3 Brine in [S]
Menu 5.5.4 Brine out A [S]
Menu 5.5.5 Brine out B [S]
Menu 5.5.6 Outdoor temp.sensor [S]
Menu 5.5.7 Room temp. sensor [S]
Menu 5.5.8 Flow temp. sensor 1 [S]
Menu 5.5.9 Flow temp. sensor 2 [S]
Menu 5.5.10 Return [S]
Pressing the Enter button returns you to menu 5.5.0.
Menu 5.6 Return [N]
Pressing the Enter button returns you to menu 5.0.
[N]
Normal menus: displayed in all menu modes.
[U]
Extended menus: Only displayed when extended or
service is selected in menu 8.1.1.
[S]
Service menus: Only displayed when service is selected
in menu 8.1.1.
