32 NIBE F1330
Installation / Adjustment
Description of functions - Basic functions
Fixed condensing
With fixed condensing the compressor start for heat
charging is regulated using the flow line sensor (FG). The
start and stop temperatures can be set in the sub-menus
to 2.7.0. The compressors and additional heating steps are
started and stopped with a 0.5 degree minus difference.
That is to say, if compressor 1 starts at 50 °C and stops at
55 °C, compressor 2 starts at 49.5 °C and stops at 54.5 °C
etc.
When the sub shunt (SV-V2) is required this can be
connected to the Expansion card 11, see the section
Description of functions - Expansion card 11 > Sub shunt.
Connection of fixed condensing
The flow line sensor (FG) is ideally placed in a submerged
tube in the working tank, boiler or the like.
To connect the sub shunt (SV-V2) see the section
Description of functions - Expansion card 11 > Sub shunt.
Floor drying function
In order to obtain the correct drying of new concrete
floors, the integrated floor drying function can be used.
The function forces the temperature on the flow line sen-
sor (FG) to fixed temperatures irrespective of the outdoor
temperature and curve settings.
The settings for the function can be found in the sub-
menus to 9.2.0.
Once the selected program is complete, control of the flow
temperature automatically returns to normal operation.
Quick guide - menu settings
fixed condensing
Menu 9.1.7 Fixed condensing [S]
Here fixed condensing is set either On or Off.
The factory setting is Off.
Menu 2.7.1 Starttemp.compressor [U]
Temperature on the flow line sensor (FG) when the first
compressor starts. The value is adjustable between 5
and 60 °C. The factory setting is 47 °C.
Menu 2.7.2 Stoptemp. compressor [U]
Temperature on the flow line sensor (FG) when the last
compressor stops. The value is adjustable between 5
and 60 °C. The factory setting is 50 °C.
Menu 2.7.3 Starttemp. additive [U]
Temperature on the flow line sensor (FG) when addi-
tional heating engages. The value is adjustable between
5 and 60 °C. The factory setting is 45°C.
Menu 2.7.4 Stoptemp. additive [U]
Temperature on the flow line sensor (FG) when addi-
tional heating disengages. The value is adjustable be-
tween 5 and 60 °C. The factory setting is 49 °C.
Quick guide - menu settings
floor drying function
Menu 9.2.1 Op-mode floor drying [S]
The operating mode for the floor drying function is set
here. Selectable modes are:
Off: Normal operation, i.e. the floor drying function is
switched off.
Own program: Two fixed temperatures in two periods
are adjustable in menu 9.2.3 to 9.2.6.
Fixed program: The flow temperature starts day 0 at
20 degrees and increases each day by 5 degrees. The
temperature has reached 45 degrees on day 5, this is
maintained on days 6 and 7. The program is terminated
by lowering the temperature on days 8 to 12 by 5 de-
grees on each day.
The factory setting is Off.
Menu 9.2.2 Floor drying day [U]
Here you can see which day the floor drying function
is on. It is also possible here to enter the floor drying
program by changing this value. The value is adjustable
from 0 to 20 days. The factory setting is 0.
Menu 9.2.3 Nos. of days per. 1 [U]
Here you set the number of days that the flow tempera-
ture shall maintain the temperature in menu 9.2.4 when
Own program in menu 9.2.1 is selected. The value is
adjustable between 1 and 10 days. The factory setting
is 5 days.
Menu 9.2.4 Temperature per. 1 [U]
Here you set the temperature to be maintained on the
flow line sensor (FG) during period 1 when Own pro-
gram is selected in menu 9.2.1. The value is adjustable
between 15 and 50 °C. The factory setting is 25 °C.
Menu 9.2.5 Nos. of days per. 2 [U]
Here you set the number of days that the flow tempera-
ture shall maintain the temperature in menu 9.2.6 when
Own program in menu 9.2.1 is selected. The value is
adjustable between 1 and 10 days. The factory setting
is 5 days.
Menu 9.2.6 Temperature per. 2 [U]
Here you set the temperature to be maintained on the
flow line sensor (FG) during period 2 when Own pro-
gram is selected in menu 9.2.1. The value is adjustable
between 15 and 50 °C. The factory setting is 35 °C.
The outline diagram with docking instructions is
available at www.nibe.eu
