List of components
25
For the Installer
FIGHTER 1210
3 Operating thermostat, standby mode
4 Collector connection, brine in (f)
5 Collector connection, brine out (r)
6 Terminal block, pumps, reversing valve
7 Service connection, high pressure
8 Switch, 1 – 0 –
9 Terminal block, incoming electric power
10 Contactor, electric module step 1
11 * Starting capacitor, compressor
12 * Start relay
13 Terminal block, compressor control
14 * Operating capacitor, compressor
15 Outside sensor
16 Heating medium pump
17 Evaporator
18 Condenser
19 Reversing valve, heating system/water heater
24 Electric module 9 kW,
supplied connected 6 kW (1210-4, 3 kW)
25 Overheating protection, immersion heater
26 Motor protection
27 Compressor
28 Operating pressostat
29 Relay card with power supply unit
30 Terminal block, relay card
33 High pressure pressostat
34 CPU-unit, control system
35 Brine pump
36 Fine wire fuse, T5AH
38 Anode (enamel)
39 Reset, motor protection
41 Low pressure pressostat
42 Service connection, low pressure
48 Expansion valve
52 Safety valve, collector side
58 Cover (enamel)
63 Particle filter (KB) R25 female.
65 Drying filter
67 Contactor, electric module step 2
68 Contactor, compressor start
69 * Contactor, compressor operation
70 Connection, heating flow ø 22 mm o.d.
71 Connection, heating return ø 22 mm o.d.
72*** Hot water circulation (VVC)
Enamel: G 20
73 Cold water
Copper/Stainless: Ø 22 mm o.d.
Enamel: G 20
74 Hot water
Copper/Stainless: Ø 22 mm o.d.
Enamel: G 20
75 Venting valve, double jacket
76 Drainage for heating system
77 Venting valve, collector system
81 Particle filter (VB) R20 female.
85 Level vessel, connection to system, R25 male
86 Temperature sensor, brine in
87 Temperature sensor, brine out
88 Temperature sensor, “hot water”
89
Temperature sensor, WW-Flow heating medium
flow
94 Temperature sensor, “HM-r”, heating medium
return
95 Type plate/serial number
96 Type plate, cooling section
97** Soft-start relay
99 Cable gland, incoming electricity
* Only FIGHTER 1210-4
** Only FIGHTER 1210-5 – 10
*** Only enamel
