Nibe Fighter 1210 - Technical Specifications

Technical specifications
FIGHTER 1210
32
For the Installer
* Compressor output only.
** Refers to the brine flow temperature/heat medium flow temperature in accordance with
EN 255.
*** With feet and connections dismantled the height is 1890 mm.
Size 4 5 7 8,5 10
Operating voltage (V) 3 x 400 V + N + PE 50 Hz
Max operating current, compressor(A)
8.0 (1-phase) 3,6 5,5 6,7 7,9
Fuse (incl. imm. heater 9 kW) (A) 25 20 20 25 25
Output, heat medium pump (W) 75 75 75 75 170
Connection heating medium, o.d. ø(mm) 22
Max pressure in storage heater(MPa)
0.9 (9 bar)
Refrigerant quantity (R407C) (kg)
1,4 1,7 2,2 2,4 2,4
Pressure drop, evaporator (kPa) 22 21 23 23 19
Max pressure collector system (bar) 3
Heating medium flow (l/s) 0,10 0,13 0,18 0,22 0,26
Max temp. (flow/return circuit) (°C) 60/50
IP 21
Volume, water heater (litres) 160
Starting current (A) 42 24 24 24 26
Fuse (incl. imm. heater 6 kW) (A) 16 16 16 20 20
Output, brine pump (W) 130 130 170 170 250
Connection collector fluid o.d. Ø (mm)
28
Volume, double-shelled (litres) 45
Max pressure in double jacket (MPa) 0.25 (2.5 bar)
Brine flow (l/s) 0,25 0,35 0,48 0,58 0,65
Available pressure, collector system (kPa) 45 40 58 53 70
Operating temperature brine system (°C) -5 – +20
Operating pressostat (bar) 24
Cut-out value pressostat HP (bar) 27
Difference pressostat HP (bar) -7
Difference pressostat LP (bar) +1,5
Cut-out value pressostat LP (bar) 1,5
Net weight (kg) 280 285 300 305 310
Delivered/supplied power* at 0/35 °C ** 4,8/1,0 6,0/1,3 8,8/1,9 10,3/2,2 11,7/2,5
Delivered/Supplied power * at 0/50 °C ** 3.9/1.2 4,8/1,5 7,1/2,2 8,5/2,5 9,9/2,9
Required headroom (mm) 1950 ***
Pressure drop, condenser (kPa) 2,7 2,6 3,4 3,2 4,4
