14 NIBE VVM 500
3x400V
Max heat pump output
1)
kW
20
Additional power immersion heater
kW
9
Electrical data
Rated voltage
400 V~ 3 NAC 50 Hz
Max operating current A
16,2
Fuse A
16
Power, HM pump W
10 - 110
Output charge pump W
10 - 110
IP class
IP 21
Heating medium circuit
Energy class circ-pump
low energy
Energy class charge pump
low energy
Max system pressure heating medium MPa
0.3 (3 bar)
Min flow l/h
500
Max HM temp ﾘC
70
Pipe connections
Heating medium, CU pipe G25
internal
Hot water connection G25
internal
Cold water connection G25
internal
Heat pump connections G25
internal
Other information
Indoor module
Area HW coil m
2
5
Volume, total indoor module l
500
Volume, buffer vessel l
80
Area, solar coil m
2
1,5
Cut-off pressure, coil MPa
1.0 (10 bar)
Max permitted pressure in indoor module MPa
0.3 (3 bar)
Capacity hot water heating
According to EN 255-3
Tap volume 40°C at Eco comfort l
235
Tap volume 40°C at Normal comfort l
303
Tap volume 40°C at Luxury comfort l
378
Idle loss according to DIN 4753-8 W
116
Dimensions and weight
Width mm
760
Depth mm
900
Height mm
1900
Required ceiling height mm
2000
Weight (excl packaging) kg
240
Part no.
069 400
1) Applies to outdoor air heat pump at 7/45 °C (outdoor temperature / Supply temperature)
IP 21
TECHNICAL SPECIfICATIONS

Nibe VVM 500 Specifications

General

Type	Indoor module
Volume	500 liters
Integrated immersion heater	Yes
Energy efficiency class, DHW preparation	A
Compatible with	NIBE air/water heat pumps
Refrigerant	Not applicable
Cooling Capacity	Matches the heat pump it is connected to.
