NIBE VVM 500 15
Outdoor sensor
NIBE™ EMK 500
Energy measurement kit
This accessory is used to
measure the amount of
energy VVM 500 produces
and supplies for hot water
and heating in the build-
ing.
Part no. 067 178
NIBE™ MODBUS 40
Communications module
MODBUS 40 enables VVM
500 to be controlled and
monitored using a design
outdoor temperature in
buildings. Communica-
tion takes place using a
MODBUS-RTU.
Part no. 067 144
NIBE™ RTS 40
Room sensor
Part no. 067 065
NIBE™ SCA 30 (solar)
Possible connection and
control of solar heating.
Part no. 067 179
NIBE™ F2026
Air/water heat pump
6 kW Part no. 064 084
8 kW Part no. 064 085
10 kW Part no. 064 086
NIBE™ F2300
Air/water heat pump
14 kW Part no. 064 063
20 kW Part no. 064 064
NIBE™ Top cabinet
2060 mm
Part no. 056 177
2160 mm
Part no. 056 178
2200-2,450 mm
Part no. 056 179
NIBE™ premium solar
packs for VVM 500
Vertical collectors:
P2 Part no. 057 102 P3 Part no. 057 103
P4 Part no. 057 104 P5 Part no. 057 105
Horizontal collectors:
PL2 Part no. 057 106 PL3 Part no. 057 107
PL4 Part no. 057 108 PL5 Part no. 057 109
NIBE™ DEH 500 (oil/elec-
tricity/gas)
Possible connection and con-
trol of external heat source.
Part no. 067 180
NIBE™ SMS 40
Communications module
SMS 40 enables VVM
500 to be controlled
and monitored via SMS
messages. The mobile ap-
plication NIBE Mobile App
can be used with a mobile
telephone with the Android
operating system .
Part no. 067 073
NIBE™ POOL 500
Pool heating
POOL 500 is an accessory
that enables pool heating
with VVM 500.
Part no. 067 181
NIBE™ RMU 40
Room unit
RMU 40 means that
control and monitoring of
the indoor module can be
carried out in a different
part of the home to where
VVM 500 is located.
Part no. 067 179
NIBE™ ELK
External electrical ad-
dition
These accessories require
accessory DEH 500 (step
controlled addition).
ELK 26
Part no. 067 074
ELK 15
Part no. 067 022
NIBE™ ECS 40/ECS41
Extra shunt group
This accessory is used when
VVM 500 is installed in
houses with two or more
different climate systems
that require different sup-
ply temperatures.
ECS 40 (max 80 m
2
)
Part no. 067 061
ECS 41 (min 80 m
2
)
Part no. 067 099
NIBE™ HR 10
Auxiliary relay
Part no. 089 423
Room sensor O-ringsCurrent sensor
The kit of supplied items is placed on top of the product.
SUPPLIED COMPONENTS
ACCESSORIES

Nibe VVM 500 Specifications

General

Type	Indoor module
Volume	500 liters
Integrated immersion heater	Yes
Energy efficiency class, DHW preparation	A
Compatible with	NIBE air/water heat pumps
Refrigerant	Not applicable
Cooling Capacity	Matches the heat pump it is connected to.
