7
M) Auxiliary relay outputs (3-way pressure terminal blocks)
4 relay outputs (e, f, g, h) for auxiliary functions. The contacts operate at 2 A @
120 VAC or 2 A @ 24 VDC.
N) Digital inputs (5-way terminal blocks)
Up to 8 receivers of the same type can be connected to the MG 3000 Module.
4 sets of Digital Inputs (a, b, c, d) for the 4 corresponding scanner inputs (a, b, c,
d). All inputs have diode protection.
O) LCD Display
Display for viewing settings and transient messages.
P) CAN Address Selection (3-way Dip Switch)
PIN FUNCTION
1 Common
2 NO
3 NC
PIN FUNCTION
1 GND
2 E1 - Release button
3 E2 - Pass-through sensor
4 E3 - Door sensor
5 E4 - Channel Inhibition
DIP 1 DIP 2 DIP 3 CAN ADDRESS
OFF OFF OFF 1*
ON OFF OFF 2
OFF ON OFF 3
ON ON OFF 4
OFF OFF ON 5
ON OFF ON 6
OFF ON ON 7
ON ON ON 8
- ENGLISH -
63
