ENGLISH – 29
LEVEL 2 FUNCTIONS (ADJUSTABLE PARAMETERS)
Entry LED Parameter LED (level) Set value Description
L4
FLASH output
(Out1)
L1 Door Open Indicator
Selects the device connected to the FLASH
output.
L2 Enabled if door closed
L3 Enabled if door open
L4 Warning light
L5 Electric latch
L6 Electric lock
L7 Suction cup
L8 Maintenance
L5 OGI output (Out2)
L1 OGI
Selects the device connected to the OGI
output.
L2 Phototest
L3 Door status
L4 Courtesy light
L5 CH 1 radio
L6 CH 2 radio
L7 CH 3 radio
L8 CH 4 radio
L6 Motor force (%)
L1 Opening 60, closing 30
Adjusts the motor force control system to
adapt it to the weight of the door during the
manoeuvres.
L2 Opening 60, closing 40
L3 Opening 70, closing 40
L4 Opening 70, closing 50
L5 Opening 80, closing 50
L6 Opening 80, closing 60
L7 Opening 90, closing 70
L8 Opening 90, closing 80
L7 Sensitivity
L1 Sensitivity deactivated
Adjusts the level of sensitivity in detecting
obstacles.
L2 Opening 10, closing 20
L3 Opening 20, closing 30
L4 Opening 30, closing 40
L5 Opening 40, closing 50
L6 Opening 50, closing 60
L7 Opening 60, closing 70
L8 Opening 70, closing 80
L8 Discharge
L1 No discharge
This function allows for releasing the
mechanical tension that accumulates in the
components after every manoeuvre. When
the closing position is reached, the motor will
perform a brief inversion to release the belt or
chain tension.
L2 min.
L3 ...
L4 ...
L5 ...
L6 ...
L7 ...
L8 max.
All the parameters can be adjusted as required without any contraindications; only the “Motor force” adjustments could require special attention:
– high force values should not be used to compensate for points of abnormal friction on the leaf. Excessive force can jeopardise the operation of the
safety system or damage the leaf
– if the “Motor Force” control is used to aid the impact force reduction system, measure the force again after each adjustment in accordance with the
EN 12445 standard
– wear and atmospheric conditions inuence the door’s movement, so the force settings should be checked periodically.
