60 – ENGLISH
Table 40
INCORPORATED RADIO RECEIVER TECHNICAL SPECIFICATIONS
Description Technical specication
Product type Incorporated two-way receiver
Decoding OXIBD: "BD" / "O-code"
Memorisable transmitters Up to 100 if memorised in “Mode 1”
Input impedance 50 Ω
Reception frequency 433.92 MHz
Transmission frequency 433.92 MHz (only BD)
Sensitivity - 108 dBm
Radiated power (ERP) < 10 mW (OXIDB)
Table 41
TECHNICAL CHARACTERISTICS OF THE INTEGRATED WI-FI MODULE (WHERE AVAILABLE)
Description Technical specication
Tipo interfaccia WIFI con
antenna interna
802.11b/g/n – 2.4GHz
Wi-Fi security OPEN/WEP/WPA-PSK/WPA2-PSK
Bluetooth ® v4.2 BR/EDR/BLE
Radiated power (EIRP) P < 20 dBm
Table 42
GUIDE TECHNICAL SPECIFICATIONS
Description SR32C SR16C SR08C SR32B SR16B SR08B SR40B
Product type
single
galvanised steel
prole
2-piece
galvanised steel
prole
single
galvanised steel
prole
single
galvanised steel
prole
2-piece
galvanised steel
prole
single
galvanised steel
prole
2 piece
galvanised steel
prole
Guide length 3200 mm
3200 (1600x2)
mm
800 mm* 3200 mm
3200 (1600x2)
mm
800 mm* 4000 mm*
Useful stroke 2800 mm 2800 mm 3500 mm** 2800 mm 2800 mm 3500 mm** 3500 mm**
Guide height 30 mm 30 mm 30 mm 30 mm 30 mm 30 mm 30 mm
Belt height - - - 10 mm 10 mm 10 mm 10 mm
Belt/chain length 6261 mm 6261 mm 7861 mm 6260 mm 6260 mm 7856 mm 7856 mm
* To be used with a 3.2 m guide to reach a length of 4 m.
** Data referred to the 4 m guide.
