CHAPTER 10 OTHERS
10.1 Model
DAG 20 00 – H – DP – P – R
10.2 Optional
(1) Basic accessories
① High precision measurement Measurement range 10µm
② Digimatic output Output to printer (DP-1) ※with cable
③ Judgment output 5 rank (-NG, -OK, OK, +OK, +NG) output (with DC I/O
base extension, connector)
Individual output is up to 16 ranks, 17 ranks and or more is code
output.
④ Rank extension function Capable of judging up to maximum of 99 ranks (OK range)
⑤ BCD output Code output of BCD data (with DC I/O base extension,
connector)
⑥ Peak measurement function Measurement value change (+PEAK, -PEAK,
TIR(=(+PEAK)-(-PEAK)), TIR/2(=(+PEAK)-(-PEAK))/2) can be
obtained.
(2) Sold separately
① Filter (DAG2000-0P-AF) Air filter + mist separator
② Filter (DAG2000-0P-AFA) Air filter + mist separator
(with auto drain)
③ Regulator (DAG2000-0P-AR) Precision regulator
④ Serial communications cable (DAG2000-0P-CB-1) D-sub 9 pin connector (EIA-232) for PC
※with sample software
(DAG2000-0P-CB-2) D-sub25 pin connector (EIA-574) for PC
(DAG2000-0P-CB-3) D-sub25 pin connector (EIA-574) for
printer
⑤ Compressed air purifier (DAG2000-0P-HAF) High moisture and oil removal rate
⑥ Foot switch (DAG2000-0P-FSW-1) Single type
(DAG2000-0P-FSW-2) 2 consecutive type
※ Note
Cannot select both [-DC] and [-BC]
P: Peak measurement function
R: Rank extension function
External I/O
N
one: standard
DP: Digimatic output
DC: Judgment output
BC: BCD output
H: High precision measurement
Type number
20
Basic model number
DAG
