DIGITAL AIR MICROMETER USERS MANUAL (Second Edition)
32
10.3 Specifications
ITEM SPECIFICATIONS REMARKS
Input module Air 1 Channel Built-in AE2000 multi
No. of measurement items 1
No. of programs 10 PROG 1~10
100
50
20
Measurement range
[unit: µm]
10
Set to each program
10µm range is optional
5
2
1
0.5
0.2
0.1
0.05
0.02
Display resolution
[unit: µm]
0.01
Set to each program
Can be selected except when range is 100
Can be selected when range is 10, 20
Can only be selected when range is 10
Main display
(Display color)
4 digits
(Red, green, orange, light dark)
Measurement value, judgment result
Multi-function display 40DOT/F.S. Measurement value is displayed in analog
dots
Automatic master calibration 8 digits (Red) Judgment result, settings values (English,
numbers)
Small range, large range
ZERO correction
Within ±50% of measurement range
Automatic master range
Sensitivity correction
Within ±50% of measurement range
And within 0.5 ~ 2.0X
Electric voltage AC85~264V Attached cable for AC100V
Frequency 50/60Hz common
Electric capacity 30VA
Dimension (L X W X H)
[unit: µm]
120 x 180 x 150 During fitting of regulator
300 (depth) mm
Weight 2.2kg 2.8kg (with regulator)
Operating temperature
0~45°C
Push button input
Foot switch
4 points Measurement command, RESET, master
calibration (2)
Serial communications RS232C 1 port Output of measurement value and
judgment result
High precision measurement
Measurement range 10µm
Digimatic output 1 port Attached DP-1 connection cable
Input signal
8 points
Measurement command, Reset
Master calibration
Program switching
READY
Master OK
Common signal at 1, 2
Judgment
output
BCD output
Output signal
Open corrector
24 points
1. Rank output
2. BCD output
1, 2 or either one
Single type Measurement command Foot switch
2 consecutive type Measurement command, RESET
Serial communications cable For RS232C
Peak measurement function +PEAK, -PEAK,
TIR(=+PEAK-(-PEAK)),
TIR/2,
(+PEAK+(-PEAK)/2
Based on measurement value change
With auto measurement function
Rank extension function 99 ranks maximum OK range
Regulator Precision regulator
Filter
Optional
Compressed air purifier When there is too much moisture and oil
