Nidec Unidrive M400 series User Manual

Unidrive M400 Quick Start Guide 27
Issue Number: 8
6 Basic parameters (Menu 0)
Menu 0 is used to bring together various commonly used parameters for basic easy set up of the
drive.
6.1 Menu 0: Basic parameters
Parameter
Range
() Default ()
Type
OL RFC-A OL RFC-A
00.001 Minimum Speed 0.00 to Pr 00.002 Hz 0.00 Hz RW Num US
00.002 Maximum Speed 0.00 to 550.00 Hz
50Hz default: 50.00 Hz
60Hz default: 60.00 Hz
RW Num US
00.003 Acceleration Rate 1 0.0 to 32000.0 s/100 Hz 5.0 s/100 Hz RW Num US
00.004 Deceleration Rate 1 0.0 to 32000.0 s/100 Hz 10.0 s/100 Hz RW Num US
00.005 Drive Configuration
AV (0), AI (1), AV Preset (2),
AI Preset (3), Preset (4),
Keypad (5), Keypad Ref (6),
Electronic Pot (7),
Torque Control (8),
Pid Control (9)
AV (0) RW Txt PT US
00.006 Motor Rated Current 0.00 to Drive Rating A
Maximum Heavy Duty
Rating A
RW Num RA US
00.007 Motor Rated Speed* 0.0 to 33000.0 rpm
50Hz
default:
1500.0 rpm
60Hz
default:
1800.0 rpm
50Hz
default:
1450.0 rpm
60Hz
default:
1750.0 rpm
RW Num US
00.008 Motor Rated Voltage 0 to 240 V or 0 to 480 V
110V drive: 230 V
200V drive: 230 V
400V drive 50 Hz: 400 V
400V drive 60 Hz: 460 V
RW Num RA US
00.009
Motor Rated Power
Factor**
0.00 to 1.00 0.85 RW Num RA US
00.010 User Security Status
Level 1 (0), Level 2 (1),
All Menus (2), Status Only (3),
No Access (4)
Level 1 (0) RW Num ND PT
00.011
Start/Stop Logic
Select
0 to 6 5 RW Num US
00.012 Input Logic Polarity
Negative Logic (0) or
Positive Logic (1)
Positive Logic (1) RW Txt US
00.015 Jog Reference 0.00 to 300.00 Hz 1.50 Hz RW Num US
00.016 Analog Input 1 Mode
4-20 mA Stop (-6),
20-4 mA Stop (-5), 4-20 mA Low (-4),
20-4 mA Low (-3), 4-20 mA Hold (-2),
20-4 mA Hold (-1), 0-20 mA (0),
20-0 mA (1), 4-20 mA Trp (2),
20-4 mA Trp (3), 4-20 mA (4),
20-4 mA (5), Voltage (6)
Voltage (6) RW Txt US
00.017
Bipolar Reference
Enable
Off (0) or On (1) Off (0) RW Bit US
00.018 Preset Reference 1 0.00 to Pr 00.002 Hz 0.00 Hz RW Num US
00.019 Preset Reference 2 0.00 to Pr 00.002 Hz 0.00 Hz RW Num US
00.020 Preset Reference 3 0.00 to Pr 00.002 Hz 0.00 Hz RW Num US
00.021 Preset Reference 4 0.00 to Pr 00.002 Hz 0.00 Hz RW Num US
00.022
Status Mode
Parameter 2
0.000 to 30.999 4.020 RW Num PT US
00.023
Status Mode
Parameter 1
0.000 to 30.999 2.001 RW Num PT US
