Connection with Component Video Signal Source Equipment
Check video signal source equipment to confirm whether the equipment has a set of available
component video output port not in use:
• If so, please continue the process.
• If not, please re-assess the method for equipment connection.
Connection of the projector with component video signal source equipment:
1. Prepare a component video - VGA (D-Sub) adapter cable, and connect the end with 3
RCA connectors with component video output port of video signal source equipment.
Match the plug color with port color: green to green, blue to blue, and red to red.
2. Connect the other end of component video － VGA (D-Sub) adapter cable (with one D-
Sub connector) with computer input -1 or computer input -2 port of the projector.
3. To use the loudspeaker of the projector in demonstration, please prepare a proper audio
cable, connect one end with audio output jack of the equipment, and connect the other end
with audio (left/right) jack of the projector.
4. Use another proper audio cable when necessary, connect one end with audio output jack of
the projector, and connect the other end with external loudspeaker (not provided).
After connection, control audio through on-screen display (OSD) menu of the projector. Built-
in loudspeaker will become mute upon connection with audio output jack.
In case of no display of selected video image after starting the projector and selecting correct
video source, please check whether video source equipment has been started and is in correct
operation. Besides, please check whether signal cable is connected correctly.
