31
Specifications
Model UT300
Display system Single 0.55" DLP template
Resolution
XGA
(1024X768 pixel
)
Aperture 2.8
Focal length 7.51mm
Screen size 30" 300"
Bulb 260W
Input terminal
D-Sub 15-pin x 2,
HDMI ×1,
Audio,
Microphone
Output terminal
VGA×1
, Audio
Control terminal RS-232 x 1, USB B x 1 (supporting firmware updating)
Scanning frequency
Horizontal frequency 31 - 100KHz
Vertical frequency 50 - 120 Hz
Environment In operation:
Temperature: C to 40°C
Humidity: 10%-80%
In storage:
Temperature: -20°C to 60°C
Humidity: 30%-85%
Power supply requirements AC 100-240V, 50 - 60Hz, 3.4A
Power consumption Maximum 310W
Overall dimension
(width
x depth x height)
327 x 137 x 248mm (projector)
383 x 191 x 342mm (outer case)
Weight
3.8 kg (including the projector and outer box)
Note: the change of design and specifications will not be further noticed.
