45
b
3
Frame the photograph.
4
Begin buffering photographs.
Compose the photograph with your
subject in the center of the frame.
Press the shutter-release button half-
way to focus (0 24). An icon will be
displayed as the camera begins
recording images to the memory
buffer. The camera continuously
adjusts focus to account for changes
in the distance to the subject while
the shutter-release button is pressed
halfway.
A
Buffering
Buffering begins when the shutter-release button is pressed halfway
and ends after about 90 seconds or when the shutter-release button is
pressed all the way down.
The optional SB-N5 flash unit is equipped with a capture illuminator
which lights during buffering (0 74). Buffering ends automatically and
the capture illuminator turns off after shooting or if the shutter-release
button is kept pressed halfway for about six seconds.
Shutter-release
button pressed
halfway to focus
Shutter-release button
pressed all the way
down
Shooting ends
Buffering

Nikon 1 v2 Specifications

General

Megapixel	14.2 MP
Camera type	MILC
Sensor type	CMOS
Sensor format	CX
Image stabilizer	No
Total megapixels	15.13 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2, 16:9
Maximum image resolution	4608 x 3072 pixels
Image sensor size (W x H)	13.2 x 8.8 mm
Still image resolution(s)	3:2:\\r 4608 x 3072\\r 3456 x 2304\\r 2304 x 1536
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Nikon 1
Minimum aperture number	-
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto focusing (AF) modes	Continuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Matrix, Spot
ISO sensitivity	160, 6400
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	160
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	30 s
Flash modes	Fill-in, Red-eye reduction, Second curtain synchro, Slow synchronization
Flash sync-speed	1/250 s
Flash guide number	5 m
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Power source type	Battery
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Resolution at capture speed	640x240@400fps
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	3 \
Display resolution (numeric)	921000 pixels
Viewfinder type	Electronic
Viewfinder screen size	0.47 \
USB version	2.0
HDMI connector type	Mini
Data network	Not supported
Eye relief	18 mm
Scene modes	Close-up (macro), Night landscape, Portrait, Landscape (scenery)
Photo effects	Black&White, Neutral, Vivid
White balance	Auto, Cloudy, Flash, Fluorescent, Incandescent, Shade, Sunny
Shooting modes	Aperture priority, Auto, Manual, Program, Shutter priority
Self-timer delay	2, 10 s
Languages support	Multi
Camera file system	DCF, DPOF, Exif 2.3
Diopter adjustment (D-D)	-3 - 2
Battery type	EN-EL21
Battery life (CIPA standard)	310 shots
Product color	White
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	45.9 mm
Width	107.8 mm
Height	81.6 mm
Weight	278 g
Weight (including battery)	337 g
