178
n
Cleaning: When cleaning the camera body, use a blower to gently remove
dust and lint, then wipe gently with a soft, dry cloth. After using the cam-
era at the beach or seaside, wipe off any sand or salt using a cloth lightly
dampened in pure water and then dry the camera thoroughly.
The lens is easily damaged. Dust and lint should be gently removed with
a blower. When using an aerosol blower, keep the can vertical to prevent
discharge of liquid. To remove fingerprints and other stains from the
lens, apply a small amount of lens cleaner to a soft cloth and wipe the
lens carefully.
Storage: To prevent mold or mildew, store the camera in a dry, well-venti-
lated area. If you are using an AC adapter, unplug the adapter to prevent
fire. If the product will not be used for an extended period, remove the
battery to prevent leakage and store the camera in a plastic bag contain-
ing a desiccant. Do not, however, store the camera case in a plastic bag,
as this may cause the material to deteriorate. Note that desiccant gradu-
ally loses its capacity to absorb moisture and should be replaced at reg-
ular intervals.
To prevent mold or mildew, take the camera out of storage at least once
a month. Turn the camera on and release the shutter a few times before
putting it away.
Store the battery in a cool, dry place. Replace the terminal cover before
putting the battery away.
Notes on the monitor and viewfinder: These displays are constructed with
extremely high precision; at least 99.99% of pixels are effective, with no
more than 0.01% being missing or defective. Hence while these displays
may contain pixels that are always lit (white, red, blue, or green) or
always off (black), this is not a malfunction and has no effect on images
recorded with the device.
Images in the monitor may be difficult to see in a bright light.
Do not apply pressure to the displays, as this could cause damage or
malfunction. Dust or lint on the displays can be removed with a blower.
Stains can be removed by wiping lightly with a soft cloth or chamois
leather. Should the monitor or viewfinder break, care should be taken to
avoid injury from broken glass and to prevent liquid crystal from the dis-
play touching the skin or entering the eyes and mouth.

Table of Contents

Other manuals for Nikon 1 v2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Nikon 1 v2 and is the answer not in the manual?

Nikon 1 v2 Specifications

General IconGeneral
Megapixel14.2 MP
Camera typeMILC
Sensor typeCMOS
Sensor formatCX
Image stabilizerNo
Total megapixels15.13 MP
Image sensor size- \
Image formats supportedJPG, RAW
Supported aspect ratios3:2, 16:9
Maximum image resolution4608 x 3072 pixels
Image sensor size (W x H)13.2 x 8.8 mm
Still image resolution(s)3:2:\\r 4608 x 3072\\r 3456 x 2304\\r 2304 x 1536
Optical zoom- x
Focal length range- mm
Lens mount interfaceNikon 1
Minimum aperture number-
Focus adjustmentAuto/Manual
Auto Focus (AF) lockYes
Auto focusing (AF) modesContinuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Light meteringCentre-weighted, Matrix, Spot
ISO sensitivity160, 6400
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)6400
ISO sensitivity (min)160
Light exposure controlProgram AE
Light exposure correction± 3EV (1/3EV step)
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed30 s
Flash modesFill-in, Red-eye reduction, Second curtain synchro, Slow synchronization
Flash sync-speed1/250 s
Flash guide number5 m
Flash exposure correction-3EV - +1EV (1/3 EV step)
Power source typeBattery
Video formats supportedH.264, MOV, MPEG4
Maximum video resolution1920 x 1080 pixels
Resolution at capture speed640x240@400fps
Audio formats supportedAAC
Memory slots1
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Display diagonal3 \
Display resolution (numeric)921000 pixels
Viewfinder typeElectronic
Viewfinder screen size0.47 \
USB version2.0
HDMI connector typeMini
Data networkNot supported
Eye relief18 mm
Scene modesClose-up (macro), Night landscape, Portrait, Landscape (scenery)
Photo effectsBlack&White, Neutral, Vivid
White balanceAuto, Cloudy, Flash, Fluorescent, Incandescent, Shade, Sunny
Shooting modesAperture priority, Auto, Manual, Program, Shutter priority
Self-timer delay2, 10 s
Languages supportMulti
Camera file systemDCF, DPOF, Exif 2.3
Diopter adjustment (D-D)-3 - 2
Battery typeEN-EL21
Battery life (CIPA standard)310 shots
Product colorWhite
Operating temperature (T-T)0 - 40 °C
Weight and Dimensions IconWeight and Dimensions
Depth45.9 mm
Width107.8 mm
Height81.6 mm
Weight278 g
Weight (including battery)337 g
