Nikon Coolpix S1 User Manual

7
First Steps
Inserting the Battery
Inserting the battery upside down or backwards
could damage the camera. Check to be sure the
battery is in the correct orientation.
The orange battery latch will pop up when the battery is fully inserted,
locking the battery in place.
First Steps
Inserting the Battery
The camera uses a rechargeable Nikon EN-EL8 lithium-ion battery (supplied).
1
Open the battery-chamber cover
Slide the cover in the direction shown () until it opens ().




2
Insert the battery
Insert the battery as shown in the label inside the
battery-chamber cover. The orange battery latch is
pushed aside as the battery is inserted.
3
Close the battery-chamber cover
Close the cover () and slide it in the direction shown until it latches ().




Battery
latch

Nikon Coolpix S1 Specifications

General

Resolution	5.1 megapixels
Optical Zoom	3x
LCD Screen Size	2.5 inches
Image Sensor	1/2.5-inch CCD
ISO Sensitivity	Auto, 50, 100, 200, 400
Weight	118g
Digital Zoom	4x
Storage Media	SD card
Type	Compact
Focal Length	35-105 mm (35mm equivalent)
Battery	EN-EL8 Lithium-ion battery
Aperture	f/3.0 - f/5.4
LCD Monitor	2.5-inch TFT LCD
Dimensions	89.9 x 57.5 x 19.7 mm (3.5 x 2.3 x 0.8 in)
Shutter Speed	4 sec to 1/350 sec
