Assembling and Connection of the System
This chapter describes how to attach this product to a microscope and how to set up connections.
WARNING
When assembling and making connections for this product, read through “
WARNING”, “ CAUTION”, and
“Handling of This Product“ at the beginning of this manual and observe the relevant precautions.
Applicable microscopes and epi fluorescence attachment
This product supports the following combinations of microscopes and epi fluorescence attachments.
Applicable microscopes and epi fluorescence attachment
Biological microscope Epi fluorescence attachment
Ti2-E, Ti2-A, and Ti2-U TI2-LA-FL-2 EPI-FL module
Ts2R-FL TS2R-F-AFL-2 D-LEDI adapter
Ni-E and Ni-U NI-FLEI-2 Epi fluorescence attachment
Ci-E, Ci-L, and Ci-S
CI-FL-2 Epi fluorescence attachment
D-FL-2 U-EPI fluorescence attachment
FN1
D-FL-2 U-EPI fluorescence attachment
NI-FLEI-2 Epi fluorescence attachment
CI-FL-2 Epi fluorescence attachment
Required tool
The following tool is required to attach this product.
• A hexagonal wrench: 2 mm across flats
