Chapter 6 Specifications
31
Remote control pad
Status display 2.7-Inch organic EL display (128 × 64 pixels)
The display can be turned on and off by using the slide switch on the left side.
Provides a beep sound (can be enabled or disabled)
Switching to a standby
state
The illuminator can be turned on and off by using the push switch on the right side.
Operating the menu Pressing the MENU button displays the operation menu on the screen.
Turn the illumination control dial to select an item, and then press the illumination
control dial to apply.
Major functions can be assigned to the Fn button.
On/off and brightness
control
Switches between the simultaneous illumination control mode and individual
illumination control mode (operation via the display)
Simultaneous illumination control mode:
Pressing the illumination control dial turns all the LEDs
on and off.
Individual illumination control mode:
Pressing the SELECT button selects a target LED.
Pressing the illumination control dial switches the LED
on and off.
Illumination control Adjustment is made by rotating the push switch with a rotary encoder.
Illumination control mode: Can be switched between the simultaneous and
individual illumination control modes.
Illumination control step: 0 to 100 (101 steps for each LED)
In simultaneous illumination control mode, brightness
can be controlled while maintaining relative brightness
between wavelengths.
• Excitation light emission synchronized to the image capture timing on the CCD
camera (time-lapse observation)
• Supports the trigger acquisition function
Operation Switches: 1 slide switch (left side)
4 push buttons (3 on the top, 1 on the right)
1 push switch with a rotary encoder
Display part: 1 OLED display
Connection Cable: Connected with a cable directly from the remote control
pad
Connection destination: D-LEDI main body REMOTE connector (14 pin)
Communication standards: Special-purpose
Power Operating power: +12 VDC
Power supply: Provided via a remote control connection cable from
the D-LEDI main body.
Applicable fluorescence filter cubes
Model name C-LED385 Fluorescence filter cube
C-LED470 Fluorescence filter cube
C-LED525 Fluorescence filter cube
C-LED625 Fluorescence filter cube
Main specifications Dedicated for D-LEDI; supports each wavelength of the LED illumination system.
Refer to “1.3 Recommended Fluorescence Filter Cubes.”
