Introduction—Getting to Know the Camera
Camera Body (continued)
Ambient light sensor: 52, 57
Self-timer lamp: 120
Flash sync terminal: 114
10-pin remote terminal: 239
Audio / video (A / V) connector
(under cover):
222
Housings for fl ash
sync and 10-pin re-
mote terminal caps
(on inside of cover)
USB connector (under cover):
224
Lens release button: 21
Focus-mode selector: 70
Battery cover latch: 16
DC-in connector
(under cover):
235
Sub-command dial:
12
Depth-of-fi eld preview button:
83
Sub-command
dial for vertical
shooting:
12
Shutter-release
button for vertical
shooting: 31
Vertical shooting shutter-
release button lock:
31, 71
Connector for
optional WT-2 /
2A or WT-1 / 1A
wireless LAN
adapter (under
cover):
235
Tripod socket
FUNC. button:
197
