5
Introduction—Getting to Know the Camera
Eyepiece shutter lever: 31, 120
Viewfi nder eyepiece:
31, 236
Delete (
) button: 35, 136
Format ( ) button: 23
Playback (
)
button: 128
Monitor:
28,
203, 241
Menu (
)
button: 39
Thumbnail ( )
button: 132
Protect ( )
button: 135
HELP button:
39
Enter (
)
button: 40
Playback zoom
( ) button: 134
Speaker: 143
Rear control panel: 9
Sensitivity (ISO)
button: 50
Image quality / size (QUAL)
button: 44, 47
White balance (WB)
button: 52–64
Microphone:
138
Microphone (
) button: 138
AF-ON (
) button for vertical
shooting: 71
Main command dial
for vertical shooting:
12
Card-slot cover
release button
(under cover):
22
AF-area mode
selector: 74
Focus selector
lock:
72
Multi selector:
14
Memory card
slot cover:
22
Memory card
access lamp:
22, 24
Main command
dial:
12
AF-ON ( )button:
71
AE / AF lock (
)
button: 78, 93
The Speaker and Microphone
Do not bring magnetic devices, such as microdrive cards, close to the built-in speaker
or microphone.
