Chapter 9 Specifications
2 DS Camera Head
- 39 -
2
DS Camera Head
DS-Qi1Mc
DS-Fi1
Image pickup
device
2/3-inch square pixel,
1.50 megapixel interline CCD
2/3-inch square pixel,
5.24 megapixel interline CCD
Color/monochrome Monochrome Color
Infrared blocking
filter
None Built in
Max. frame rate
*1
19.0 fps (1.3M progressive scan)
31.5 fps (VGA progressive scan)
46.8 fps (QVGA progressive scan)
24.2 fps (center scan)
5.9 fps (5M interlaced)
10.0 fps (1.3M interlaced)
12.0 fps (1.3M progressive scan)
23.3 fps (center scan)
Number of
recording pixels
1280 x 1024
640 x 480
320 x 240
2560 x 1920
1280 x 960
640 x 480
Quantization 12 bits
Sensitivity Equivalent to ISO 800 Equivalent to ISO 64
(Settings: Tone 3; camera sensitivity x1)
Lens mount C mount
Supported lenses:
Protruding no more than 10 mm from the mount surface into the camera.
Image circle: φ11 mm
Dimensions 77 (W) x 76 (D) x 44 (H) mm
Weight 290 g 260 g
Fixing tripod
mount
Tripod screw for cameras
Body color Black (with logo) White (with logo)
CCD cooling
(Peltier cooling) --------
*1 The CCD mode is indicated in parentheses.
The frame rate figure indicates the maximum frame rate of the camera.
The image display speed of the PC varies significantly depending on the PC’s operating
environment and the USB data transfer rate.
Given below are approximate maximum frame rates for image display:
640 x 480 pixels x 3 colors (RGB) 15 fps
640 x 480 pixels x one color (monochrome) 30 fps
