Chapter 9 Specifications
2 DS Camera Head
- 41 -
DS-2Mv DS-2MBW DS-2MBWc DS-5M DS-5M c
Image pickup
device
1/1.8-inch square pixel,
2.11 megapixel interline CCD
2/3-inch square pixel,
5.24 megapixel interline CCD
Color/monochrome Color Monochrome Color
Infrared blocking
filter
Built in None Built in
Max. frame rate
*1
15.0 fps (2M progressive scan)
20.0 fps (800*6 progressive scan)
30.0 fps (800*5 progressive scan)
30.0 fps (center scan)
3.8 fps (5M interlaced)
6.8 fps (1.3M interlaced)
7.5 fps (1.3M progressive scan)
15 fps (center scan)
Number of
recording pixels
1600 x 1200
800 x 600
400 x 300
2560 x 1920
1280 x 960
640 x 480
Quantization 12 bits
Sensitivity Equivalent to
ISO 100
Equivalent to ISO 350 Equivalent to ISO 64
(Settings: Tone 3; camera sensitivity x1)
Lens mount C mount
Supported lenses:
Protruding no more than 10 mm from the mount surface into the camera.
Image circle: φ8.9 mm Image circle: φ11 mm
Dimensions 91 (W) x 76 (D) x 41 (H) mm
Weight 260 g 290 g 260 g 290 g
Fixing tripod
mount
Tripod screw for cameras
Body color White
(with logo)
White
(with logo)
Black
(with logo)
White Black
CCD cooling
-------- -------- (Peltier cooling) -------- (Peltier cooling)
*1 The CCD mode is indicated in parentheses.
The frame rate figure indicates the maximum frame rate of the camera.
The image display speed of the PC varies significantly depending on the PC’s operating
environment and the USB data transfer rate.
Given below are approximate maximum frame rates for image display:
640 x 480 pixels x 3 colors (RGB) 15 fps
800 x 600 pixels x 3 colors (RGB) 10 fps
800 x 600 pixels x one color (monochrome) 30 fps
