Chapter 2 Switches and Controls
49
2
(1) Diopter Ring
(2) Revolving
nosepiece
(3) Sta
g
e
(4) S
p
ecimen holder
(5) Condenser
aperture diaphragm
(7) Condenser aperture
diaphragm
(8) Blue filter and the
filter holder
(6) Condenser Clamp
Screw
(16) Condenser focus knob
(19) Coarse focus knob
torque adjustment ring
(20) Name
p
late
(18) Coarse focus Knob
(17) Fine focus knob
(22) AC Inlet
(21) Voltage selector
(Fuse holder)
(13) Fine focus knob
(10) Lateral stage
motion (X Axis) knob
(9) Longitudinal stage
motion (Y Axis) knob
(15) Bri
g
htness control dial
(14) Power switch
(12) Field diaphragm
centering screws
(11) Field dia
p
hra
g
m rin
g
