Chapter 4 Specifications
41
Specifications
Tube Binocular tube (binocular section 100%)
Trinocular tube F (Binocular : adapter = 100:0, 0:100)
Trinocular tube T (Binocular : adapter = 100:0, 20:80, 0:100)
Ergonomic tube (Binocular section 100%)
(with DSC port mounted, binocular : DSC port = 50:50)
Quadrocular tilting tube (Binocular : adapter = 100:0, 0:100)
(with DSC port mounted, binocular : adapter : DSC port = 0:0:100)
Arm Standard arm
Contact arm: Required for motorized operation
Nosepiece Universal quintuple, BD quintuple, sextuple, sextuple with analyzer slot, DIC sextuple, intelligent DIC
sextuple, septuple intelligent, motorized DIC sextuple, and motorized septuple
Substage Two types: for standard stage and rotatable ceramic coated stage, one for rotatable ceramic coated
stage is equipped with rotatable stage centering screws
Attached to the elevating section of the main body
Stage • Right/left handle stage (with specimen holder)
• Right/left handle ceramic coated stage (with specimen holder) (Right handle ceramic coated stage
without specimen holder as well)
• Right/left handle rotatable ceramic coated stage (with specimen holder)
Travel range: X: ±78 mm, Y: ±54 mm
Rotation angle: The stage can be rotated clockwise by 195° and counterclockwise by 7° from the
reference position (rotation angle 0°).
Condenser holder Equipped with condenser focus knob, condenser centering screws.
Attached to a substage
Condenser Universal condenser: Attach optical modules for differential interference contrast, phase contrast, or
dark-field microscopy to a turret.
C-C phase turret condenser: Optical module for phase contrast and dark-field and shutter embedded
DIC condenser (oil): Differential interference contrast optical module OIL (slider) attached
Other condensers: Abbe condenser, achromat condenser, dark field condenser (dry and oil),
aplanatic condenser, X LWD condenser, 2-100X slide achro condenser, 1-100X achromat swing-out
condenser
Ni-U microscope input ratings 100-240VAC, 50/60Hz, 1.7A
Power cord • When used in 100-120 V regions outside Japan
UL listed detachable power cord set, 3 conductor grounding
(3 conductor grounding Type SVT, No.18 AWG, 3 m long maximum, rated at 125 VAC minimum)
• When used in 220-240 V regions
Detachable power cord set approved according to EU/EN standard, 3 conductor grounding
(3 conductor grounding Type H05VV-F, 3 m long maximum, rated at 250 VAC minimum)
• When used inside Japan
PSE approved detachable power cord set, 3 conductor grounding
(3 conductor grounding Type VCTF 3 x 0.75 mm
2
, 3 m long maximum, rated at 125 VAC minimum)
