142
Viewing Accessories
Eyepiece Correction Lenses
Five lenses — –3, –2, 0, +1 and +2m
–1
— are available. When
used with the diopter adjustment dial of the Multi-Meter Finder
DP-30, the combined adjustment range will extend from –5 to
+4m
–1
.
Rubber Eyecup DK-2
The eyecup prevents stray light from entering the viewfinder
from the rear and allows eyeglass wearers to use the F5 without
fear of scratching their glasses.
Right-Angle Viewing Attachment DR-4
Excellent for copy work, the DR-4 provides an upright, unre-
versed image for right-angle viewing. Individual eyesight adjust-
ments are possible.
Eyepiece Magnifier DG-2
Provides 2X magnification of the central portion of the finder
image with Eyepiece Adapter DK-7. Eyesight adjustment
provided. Useful for critical focusing in close-up photography.
Eyepiece Adapter DK-7
Lets you attach the DR-3 or DG-2 to the Multi-Meter Finder
DP-30’s eyepiece.
DR-4
DG-2
DK-2
DK-7
