Nikon MONARCH 2000 - Technical Specifications

20
En
Fr
 Specifications
Measurement range (actual distance)
*1
7.3-1,820 m/8-2,000 yd.
Maximum measurement distance (reflective)
*1
1,820 m/2,000 yd.
Maximum measurement distance (tree)
*1
1,090 m/1,200 yd.
Maximum measurement distance (deer)
*1
1,000 m/1,100 yd.
Distance display (increment)
Every 0.1 m/yd.
Accuracy (actual distance)
*2
±0.5 m/yd. (shorter than 700 m/yd.)
±1.0 m/yd. (700 m/yd. and over, shorter than 1,000 m/yd.)
±1.5 m/yd. (1,000 m/yd. and over)
Magnification (×) 6
Effective diameter of objective lens (mm) 21
Angular field of view (real) (˚) 7.5
Eye relief (mm) 18.0
Exit pupil (mm) 3.5
Diopter adjustment ±4 m
-1
Dimensions (L × H × W) (mm/in.) 96 × 74 × 42/3.8 × 2.9 × 1.7
Weight (g/oz.) Approx. 175/6.1 (without battery)
Operating temperature (˚C/˚F) -10 — +50/14 — 122
Operating humidity (%RH) 80 or less (without dew condensation)
Power source
CR2 lithium battery × 1 (DC 3V)
Automatic power shut-off (after approx. 8 sec. unoperated)
Structure
Waterproof (up to 1 m/3.3 ft for 10 minutes)
*3
, fogproof
Battery chamber is rainproof — JIS/IEC protection class 4 (IPX4)
equivalent (under Nikon’s testing conditions)
*4
Electromagnetic compatibility
FCC Part15 SubPartB class B, EU:EMC directive, AS/NZS, VCCI classB,
CU TR 020, ICES-003
Technical notes
