VI. SPECIFICATIONS
48
1. Main Unit
● Telescope
Image: Erect
Magnification: 30×
Effective objective diameter: 45mm (1.77in)
Field of view: 1°20' (2.3m at 100m/2.3ft at 100ft)
Minimum focusing distance: 0.7m (2.3ft)
Stadia multiplier: 100
Stadia addend: 0
● Angle Measurement
NE-101 NE-100
Minimum display
5"/10",
1mgon/2mgon,
0.02Mil/0.05Mil
10"/20",
2mgon/5mgon,
0.05Mil/0.1Mil
Accuracy (Standard
deviation based on
DIN18723)
7"/2mgon 10"/3mgon
Reading system: Electronic readout by incremental optical
encoder
• Single-side horizontal angle reading
• Single-side vertical angle reading
Display unit: Degree, Gon, or Mil
● Optical Plummet
Image: Erect
Magnification: 2.2×
Field of view: 5°
Focusing range: 1.3m (4.16ft) fixed
