12
Set-up
Mounting
Transport into the dwelling
The ventilation unit is delivered assembled and wrapped on a pallet. You can use Nilan lifting trolley, with which the unit can be lifted
directly off the pallet and into the building without heavy lifting. If the exchanger box is removed, the unit can be manoeuvred through
an ordinary door.
Disassembling the exchanger box
It may be necessary to disassemble the exchanger box when servicing fans and other components. It can also facilitate transport if the
unit is to pass through a door.
1.Remove the 8-pole plug located at the top of the unit
and push it down into the hole.
2. Demount the front plate.
a: loosen the thumb screws and remove the filter door.
b: lift up the large door and remove it. Detach the RJ plug
from the control panel on the rear side of the large door.
Unscrew the cover plate under the large door and remove it.
3. Pull out the T4 sensor from the heat exchanger 4. Pull out the heat exchanger from the unit.
