nilan CTS602 HMI Installation Instructions

Control panel
C
onnection of CTS602 HMI control panel
The control panel is connected to the CTS602 circuit board and is installed in the front part of the unit.
Use this if you want to move the control panel away from the unit.
At the factory the control panel has been mounted on the large door
8-pole plug located on top of the unit.
