Temperature sensor overview
T11
T10
T2 T1T5
T6
RH
T12
T1
T2
T10
Temperature sensor in the unit Temperature sensor in the hot water tank
T1: Outdoor air (install in the outdoor air duct)
T
2: Supply air
T5: Condenser
T6: Evaporator
T10: Extract air
RH: Humidity sensor
T11: Top of tank
T
12: Bottom of tank
8
