77NILES AUDIO CORPORATION – 1-800-BUY-HIFI – 305-238-4373
RS-232 CONTROL PROTOCOLS
ZR-6 Response: r[type],[com #],FAIL,[fcode][cr]
r
indicates a ZR-6 command response
[type] identifies the response type
znc = zone command
znt = zone transport command
src = source command
srt = source transport command
spc = special command
syc = system command
zsc = zone specific command
[com #], the number of the failed command (see table)
FAIL, indication the command failed
[fcode] code number of the failure type:
1 Cannot allocate memory to process message
2 Invalid Command
3 Incomplete message: missing command
4 Incomplete message: missing parameter
5 Cannot allocate memory to process command
6 Cannot change the zone: invalid zone number
7 Invalid key code (command type)
8 Is not allowed hold flag
9 Is not allowed repeat flag
10 Invalid flag
11 Is not allowed flags
12 Cannot find the zone: invalid index
13 Cannot find the source: invalid index
14 Cannot find the soft key: invalid index
15 Cannot find the menu item: invalid index
16 IP address is not defined
17 Alternative behavior is not supported
18 ZR-6 is waiting previous special command answer
19 ZR-6 is waiting previous special command setting
answer
20 Parameter 1 is out of range
21 Parameter 2 is out of range
22 Parameter 3 is out of range
23 Parameter 4 is out of range
24 Invalid parameter: too many dots
25 Invalid parameter: must be all numbers
26 Menu is not available
27 Pound (#) or bytes do not match with the string
value bytes that were received
28 Menu does not support alphanumeric search
[cr] is a carriage return
8) Erase EEPROM – erases all confi guration input and tuner
presets, restoring the ZR-6 to the factory default condition.
NOTE: LEARNED IR COMMANDS ARE NOT ERASED.
Syntax: syc,3,[cr]
syc,
indicates the command type (system command)
3, indicates this is an EEPROM erase command
[cr] is a carriage return
EXAMPLE :
Command: syc,3,[cr] (erases the EEPROM)
ZR-6 Response:
rsyc,3,[cr] (EEPROM has been erased)
rsyc, identifies a response to a system command
3, indicates the EEPROM was erased
[cr] is a carriage return
CONTROL COMMAND STRINGS
(CONTINUED ON NEXT PAGE)
