23NILES AUDIO CORPORATION – 1-800-BUY-HIFI – 305-238-4373
OVERVIEW
The ZR-6 MultiZone Receiver can be integrated with an external control system that uses RS-232 serial communication.
RS-232 PORT
A 3.5 mm stereo mini-jack is used to provide RS-232 serial communication so the ZR-6 MultiZone Receiver can be monitored and
controlled by an external control system. Please refer to the Appendix for the RS-232 integration control protocols.
SYSTEM WIRING DIAGRAMS
ADDING AN EXTERNAL RS-232 CONTROL SYSTEM TO THE ZR-6 MULTIZONE RECEIVER
Figure 7. Connecting an external RS-232 control system
