TECHNICAL DATA (Per BA 551, BA 551D, BA 551CD, BA 611D) (continues)
Technical data for machines with brush/pad-holder deck
Model
BA 551
(1 brush/pad-holder,
without drive system)
BA 551D
(1 brush/pad-holder, with
drive system)
BA 611D
(2 brushes/pad-holders,
with drive system)
Cleaning width 21,0 in (530 mm) 21,0 in 530 mm () 24,0 in (610 mm)
Squeegee width 30,0 in (760 mm) 32,0 in (810 mm)
Machine maximum length 52,1 in (1.323 mm) 51,6 in (1.311 mm)
Machine width without squeegee 21,3 in (541 mm) 25,4 in (646 mm)
Brush diameter 21,0 in (530 mm) 12,0 in (305 mm)
Deck right/left offset 3/- in (77/- mm) 3,4/3,1 in (87/80 mm)
Brush distance from the ground (when lifted) 2,3 in (59,5 mm) 2,7 in (69,5 mm)
Weight without batteries and with empty tanks 194,0 lb (88 kg) 225,0 lb 102 kg ()
Maximum weight with batteries and full tanks 520,3 lb (236 kg) 551,1 lb 250 kg ()
Brush motor power 0,64 hp (480 W) 0,47 hp (350 W)
Brush speed 153 rpm 230 rpm
Brush/pad-holder pressure with extra-pressure function turned off 45,2 lb (20,5 kg)
Brush/pad-holder pressure with extra-pressure function turned on 61,3 lb (27,8 kg)
Technical data for machines with cylindrical brush deck
Model
BA 551CD
(2 cylindrical brushes, with drive system)
Cleaning width 20,0 in (510 mm)
Squeegee width 30,0 in (760 mm)
Machine maximum length 49,3 in (1253 mm)
Machine width without squeegee 22,7 in (575,5 mm)
Cylindrical brush size (diameter x length) 4,3 x 20,0 in (110 x 485 mm)
Deck right/left offset 3,7/0,2 in (94/4,5 mm)
Brush distance from the ground (when lifted) 1,5 in (39,5 mm)
Weight without batteries and with empty tanks 247,0 lb (112 kg)
Maximum weight with batteries and full tanks 573,2 lb (260 kg)
Brush motor power 0,54 hp (400 W)
Cylindrical brush rotation speed 570 rpm
Cylindrical brush pressure 58,4 lb (26,5 kg)
