BRUSH MOTOR ELECTRICAL INPUT CHECK (For BA 451, BA 451D, BA 531, BA 531D)
WARNING!
This procedure must be performed by qualied personnel only.
Check
If the tank (21) contains recovery water:1.
Drive the machine to the appointed recovery water disposal area.•
(For • BA 451D, BA 551D) Turn the ignition key (80) to “0”.
(For • BA 451, BA 551) Turn off the switches (71) and (73).
Empty the recovery water tank (21) with the hose (16).•
Drive the machine on a level oor.2.
Remove the brush/pad-holder.3.
Lower the deck by pressing the pedal (11).4.
- (For 5. BA 451D, BA 551D) Turn the ignition key (80) to “0”.
- (For BA 451, BA 551) Turn off the switches (71) and (73).
Grasp the handle (41) and carefully lift the tank (40).6.
(For machines with 7. EcoFlex™ system)
Unscrew the union (A).•
Remove the detergent tank (B).•
Remove the screws (C).•
Slightly lift the tank holder (D) and mark the position of the connectors (E) and (F) (to reinstall them correctly), which must •
be as follows:
Connector (E): white cable•
Connector (F): blue cable•
Disconnect the connectors (E) and (F) from the detergent pump (G).•
Disconnect the hoses (H) from the union (I) and remove the tank holder (D) together with the detergent pump (G).•
Apply the amperometric pliers (J) on one cable (K) of the brush motor (L).8.
(For 9. BA 451D, BA 551D) Turn the speed adjuster (4) to idle and turn the ignition key (80) to “I”.
Turn on the brush/pad-holder by pressing the switch (71) and check that the motor electrical input is 3 - 4 A at 24 V. Turn off 10.
the brush/pad-holder by pressing the switch (71).
(For BA 451D, BA 551D) Turn the ignition key (80) to “0”.
Remove the amperometric pliers (J).
If the electrical input is higher, perform the following procedures to detect and correct the abnormal input:
NOTE
If the electrical input is higher than the maximum allowed value, the 3 battery warning leds (81) ash simultaneously.
Check the tightening of F1 fuse screw (see the procedure in Fuse Check/Replacement paragraph).•
Check if there is dust or dirt (ropes, cables, etc.) on the brush/pad-holder hub.•
Check the motor carbon brushes (see the procedure in the relevant paragraph).•
Disassemble the motor (see the procedure in the relevant paragraph), and check the condition of all its components.•
If the above-mentioned procedures do not lead to a correct electrical input, the motor must be replaced (see the procedure in
the relevant paragraph).
Reset
Perform steps 3 to 7 in the reverse order.11.
