GENERAL INFORMATION
SERVICE MANUAL
ENGLISH
Micromatic
TM
M17B - Micromatic
TM
M17E 9097091000(1)2007-06
5
TECHNICAL DATA
General MICROMATIC M17B MICROMATIC M17E
Cleaning width 17.0 in (430 mm)
Machine width (without squeegee) 22.4 in (570 mm)
Minimum machine length with adjustable handlebar 39.2 in (997 mm)
Minimum machine height with adjustable handlebar 28.7 - 32.9 in (730 - 836 mm)
Squeegee width with straight squeegee (standard) 28.3 in (720 mm)
Squeegee width with curved squeegee 30.0 in (760 mm)
Minimum turning radius 29.5 in (750 mm)
Machine net weight 138.9 lb (63 Kg) 143.3 lb (65 Kg)
Machine weight in running condition 282.2 lb (128 Kg) 194 lb (88 Kg)
Central (xed axle) wheel diameter 9.8 in (250 mm)
Brush/pad diameter 17.0 in (430 mm)
Max pressure wheel on the ground (*) 72.5 psi (0.5 N/mm
2
)
Brush/pad pressure on the ground (with full tank) 50.6 lbs (23 Kg) 61.6 lb (28 Kg)
Battery compartment size (length x width x height)
13.8 x 13.8 x 10.2 in
(350 x 350 x 260 mm)
-
(*) the machines is tested in the following conditions:
max size battery
max size brush deck / squeegee
solution tank full
optionals installed
weight veried on each wheel
print area veried on concrete for each wheel
result expresses as max. value for front and max value for rear wheels
Performance MICROMATIC M17B MICROMATIC M17E
Vacuum 41.5 in H
2
O (1,055 mm H
2
O) 51.8 in H
2
O (1,316 mm H
2
O)
Sound pressure level 67 dB(A) 76 dB(A)
Vacuum system motor power 300 W 550 W 60 Hz
Brush/pad motor power 520 W 550 W 60 Hz
Brush/pad holder motor speed 135 rpm 170 rpm
Battery voltage 24 V -
System voltage - 115 V
Standard batteries 12 V, 87 Ah -
Clean water tank capacity 6 gal (23 liters)
Recovery water tank capacity 5.5 gal (21 liters)
Solution ow (min/max) 0.08-0.26 gallons/min (0.3-1 liters/min)
•
•
•
•
•
•
•
