Vacuum cleaner description
Optional kits
Please contact the manufacturer’s sales network for
information on optionals.
Instructions for installing the optionals are included in the
conversion kit.
WARNING!
Use only supplied and authorized genuine spare parts.
Accessories
Various accessories are available; refer to the manufacturer’s
accessory catalogue.
WARNING!
Use only genuine accessories supplied and
authorized by the manufacturer.
Packing and unpacking
Dispose of the packing materials in compliance with the laws
in force.
Figure 3
Model
S2
(50L)
S3
(50L)
S3
(100 L)
A (in) 27.6 27.6 27.6
B (in) 33.9 33.9 33.9
C (in) 68.9 68.9 68.9
Weight with
packaging (lbs.)
176 190 196
Unpacking, moving, use and storage
Operate on at, horizontal surfaces.
The load-bearing capacity of the surface the vacuum cleaner
is placed on must be suitable for bearing its weight).
Vacuum Cleaner Parts and Labels
Figure 1
1. Model code, Technical Specications (see table on page
6), Serial N°., CE Mark, Year of manufacture, Nominal
voltage.
2. Dust container
3. Dust container release lever
4. Inlet
7. Accessories compartment
9. Exhaust air outlet
10. Attention plate: Draws the operator’s attention to
the fact that the lter must only be shaken when the
vacuum cleaner is turned off (see also par. “Primary lter
shaker”).
11. Plug for connecting the vacuum cleaner to an electrical
socket.
Figure 2
This vacuum cleaner creates a strong air ow which is drawn
in through the inlet (4 - Fig. 1) and blown out through the
exhaust outlet (9 - Fig. 1).
Before turning on the vacuum cleaner, t the vacuum hose
into the inlet and then t the required tool on to the end part
(refer to the manufacturer’s accessory catalogue or Service
Centre).
The diameters of the authorized hoses are given in the
technical specications table.
The vacuum cleaner is equipped with a primary lter which
enables it to be used for the majority of applications.
Besides the primary lter, which retains the most common
types of dust, the vacuum cleaner can be tted with a HEPA
lter with a higher ltering capacity for ne dusts and dusts
that are hazardous to health.
