USER MANUAL ENGLISH
9099596000 - SC450 9
ACCESSORIES/OPTIONS
In addition to the standard components, the machine can be equipped with the following accessories/options, according to the
machine specic use:
– Brushes of different materials
– Pads of different materials
– Polyurethane squeegee blades
– Removable solution feed hose
For further information concerning the optional accessories, contact an authorised Retailer.
TECHNICAL DATA
Model SC450
Machine length 1,174 mm
Machine width without squeegee 559 mm
Machine height 980 mm
Cleaning width 530 mm
Squeegee width 760 mm
Brush diameter 530 mm
Solution tank capacity 40 litres
Recovery tank capacity 45 litres
Min/max solution ow 0.4 ÷ 1.6 L/min
ECO solution ow 0.4 L/min
Front wheel diameter 254 mm
Wheel specic pressure on the oor 3.1 N/mm
2
Brush motor power 1,100 W, 50-60 Hz
Brush speed 150 rpm
Brush/pad pressure on the oor with full tank and lowered squeegee 40 kg
Vacuum system motor power 550 W, 50-60 Hz
Vacuum system circuit capacity 1,200 mm H
2
O
Maximum gradient when working 2 %
Sound pressure level at workstation (ISO 11201, ISO 4871, EN 60335-2-72) (LpA) 70 dB(A) ± 3 dB(A)
Machine sound pressure level (ISO 3744, ISO 4871, EN 60335-2-72) (LwA) 89 dB(A)
Vibration level at the operator’s arms (ISO 5349-1, EN 60335-2-72) < 2.5 m/s
2
Power supply 230 V - 50-60 Hz
Protection class (IP) X4
Protection class (electric) I
Electrical system voltage 230 V - 50 Hz
Total absorbed power 1.7 kW
Weight with empty tanks 94 kg
Gross vehicle weight (GVW) 124 kg
Shipping weight 121 kg
