Nilfisk-ALTO NEPTUNE 1 Service Manual

B
Technical data
NEPTUNE 1&2_EN_Ver.2.1_45/2014
21
Parent item no: Description:
107145008 GERNI NEPTUNE 2-26 240/1/50/15
Service data Unit Value
Model
GERNI NEPTUNE 2-26
Item no.
107145008
TECHNICAL DATA
PUMP:
Pump pressure water bar
134
Pressure pump outlet @ Qiec bar
124
Pressure gun outlet @ Qiec bar
120
Retaining pressure* bar
-
Flow. Qiec l/min
8,17
Suction height dry m
-
Suction height primed m
-
Pump type
NA2
Number of pistons
3
Piston type
Full Ceramic
Stroke mm
1
Pump oil type
Agip Rotra
Pump oil amount l
0,2
ELECTRIC:
Electric data V/ph/Hz/A/kW
240V/1ph/50Hz/14,5A/3,4kW
Control voltage V
240
Highvoltage (HV) test voltage kV
1,5
HV Insulation resistance MΩ
1
Earth circuit resistance Ω
0,2
Pump revolutions rpm
2800
Electrical diagram no.
106421566
