F
Service / Repair
NEPTUNE 1&2_EN_Ver.2.1_45/2014 92
1. Fuel solenoid
2. Fuel pump
3. Burner motor
4. Burner housing
5. Fuel filter
6. Fan
7. Fan cover
1
2
3
4
5
6
7
Fig.F.77: Burner unit.
Burner Unit.
