Nilfisk-ALTO NEPTUNE 1 Service Manual

F
Service / Repair
NEPTUNE 1&2_EN_Ver.2.1_45/2014 90
Fuel tank.
Fig.F.71. Fuel tank

Dismount the 2 cord hooks on the back of
the fuel tank.
 Dismount the detergent tank and the fuel ho-
ses in the top of the fuel tank.
 Lift the tank of the wheel shaft.
 Empty the fuel of the tank.
FIG.F. 72: Fuel level sensor

Loosen the nut and drag out the sensor.
 Disconnect the plug on the cord and replace
the sensor if necessary.
FIG.F.73: Fuel level sensor
Check resistance.
Empty tank - open.
Full tank - closed.
1. Detergent tank.
2. Return hose.
3.Venting system.
4.Outlet hose.
5. Level sensor.
6. Cord hook.
7. Fuel lid.
8. Strainer.
Fig.F.70: Fuel tank - Overview.
