Nilfisk-ALTO NEPTUNE 1 Service Manual

B
Technical data
NEPTUNE 1&2_EN_Ver.2.1_45/2014
31
Parent item no: Description:
107145014 NEPTUNE 2-41X EU 400/3/50
Service data Unit Value
Model
NEPTUNE 2-41 X
Item no.
107145014
TECHNICAL DATA
PUMP:
Pump pressure water bar
181
Pressure pump outlet @ Qiec bar
Pressure gun outlet @ Qiec bar
154
Retaining pressure* bar
-
Flow. Qiec l/min
11,1
Suction height dry m
-
Suction height primed m
-
Pump type
NA2
Number of pistons
3
Piston type
Full Ceramic
Stroke mm
1
Pump oil type
Agip Rotra
Pump oil amount l
0,2
ELECTRIC:
Electric data V/ph/Hz/A/kW
400V/3ph/50Hz/9A/5.1KW
Control voltage V
400
Highvoltage (HV) test voltage kV
1,5
HV Insulation resistance MΩ
1
Earth circuit resistance Ω
0,2
Pump revolutions rpm
2800
Electrical diagram no.
106421563

Nilfisk-ALTO NEPTUNE 1 Specifications

General

Brand	Nilfisk-ALTO
Model	NEPTUNE 1
Category	Pressure Washer
Language	English
