Nilfisk-ALTO NEPTUNE 1 Service Manual

B
Technical data
NEPTUNE 1&2_EN_Ver.2.1_45/2014
39
Parent item no: Description:
107145019 NEPTUNE 2-20 US 115/1/60/20
Service data Unit Value
Model
NEPTUNE 2-20
Item no.
107145019
TECHNICAL DATA
PUMP:
Pump pressure water bar
57
Pressure pump outlet @ Qiec bar
Pressure gun outlet @ Qiec bar
48
Retaining pressure* bar
-
Flow. Qiec l/min
8
Suction height dry m
-
Suction height primed m
-
Pump type
NA2
Number of pistons
3
Piston type
Full Ceramic
Stroke mm
1
Pump oil type
Agip Rotra
Pump oil amount l
0,2
ELECTRIC:
Electric data V/ph/Hz/A/kW
115V/1ph/60Hz/20A/2.1KW
Control voltage V
115
Highvoltage (HV) test voltage kV
1,5
HV Insulation resistance MΩ
1
Earth circuit resistance Ω
0,2
Pump revolutions rpm
3360
Electrical diagram no.
106421565

Nilfisk-ALTO NEPTUNE 1 Specifications

General

Brand	Nilfisk-ALTO
Model	NEPTUNE 1
Category	Pressure Washer
Language	English
