copyright © 2012 BMI J6 transmitter
Empfänger
Kanälen wie abgebildet.
1 Querruder Kanal
2 Höhenruder Kanal
3 Gas Kanal
4 Seitenruder Kanal
5 Kreisel oder Einziehfahrwerk
6 Pitch / Flaps Kanal
Zuerst den Sender einschalten, nächstens den Empfänger.
Werkseitige Einstellungen für die Modelle 100-3D, 125-3D &
180-3D
2200
We: Shanghai Nine Eagles Electronic Technology
Co.,Ltd, No. 818 ,Fngrao road, Malu, Jiading District, Shanghai,
China
Declare under our own responsibility that the product:
J6
To which this declaration refers conforms with the relevant standards or
other standardising documents is in compliance with the essential re-
quirements and other relevant provisions of the European directive1999/
EC/EC. The product ful l the norms and/or documents below:
CEM/EMC (art.3.1b): EN 301 489-01 V1.8.1 & EN 301 489-03 V1.4.1
Spectre/Spectrum (art.3.2): EN 300 440-2 V1.2.1, EN 300 440-1 V1.5.1
Electrical safety: EN60950-1:2006+A11:2009
Place and date (of this DoC):28/12/2009
Signed by the manufacture:Shi Rui Date
Name and signature of person responsible
De overeenstemmingsverklaring is beschikbaar op:
www.bmi-models.com/download/nineeagles-J6.pdf
SOLO PRO 100 3D + 125-3D SOLO PRO 180 3D
Modeltype: Helicopter Helicopter
Swash plate :
SERVO REVERSE
CH1: REV REV
CH2: NOR NOR
CH3: NOR NOR
CH4: REV NOR
CH5: NOR NOR
CH6: NOR NOR
Dual Rate Low High Low High
CH1: 80 100 80 100
CH2: 80 100 80 100
CH4: 80 100 80 100
Curve (Expo)
CH1: -40E -50E
CH2: -45E -50E
CH4: 00E 00E
Throttle Curve CH3
dot 1: 000 000
dot 2: 018 040
dot 3: 075 060
dot 4: 087 085
dot 5: 100 100
Pitch Curve CH6 NORMAL TH NORMAL TH
dot 1: 042 032 040 035
dot 2: 045 040 045 043
dot 3: 055 050 055 052
dot 4: 058 060 058 058
dot 5: 068 068 065 065
Gyro 027 020
TRIM CH1: 0 CH1: 0
CH2: 0 CH2: 0
CH4: 0 CH4: 0
