• Screw on nut (18)
(18)(18)
(18) and tighten up Fig. 17.
Fig. 17 Fig. 18
• Insert the two keys (22)
(22)(22)
(22) and install the previously-greased O-ring (20
(20(20
(20)
) )
) Fig. 18 .
The two keys (22)
(22)(22)
(22) must be inserted flush with the inside diameter of the slot.
• Push centering scale (17)
(17)(17)
(17) with a slight turning movement to the stop but do not yet tighten screw (19)
(19) (19)
(19) (black) Fig.
19.
Fig. 19
If the centering scale (17)
(17)(17)
(17) cannot be pushed over the O-ring the two keys (22)
(22)(22)
(22) are not properly.
The centering device must now be calibrated in the next operating step.
