Symbol
SymbolSymbol
Symbols
ss
s
Please adhere strictly to the work practices and procedures indicated by this pictogram. Non-adherence could
cause damage to the tool or the cable.
This pictogram serves to illustrate the working and operating procedures which must be adhered to, as well as to
give important information about how the tool works.
Product description
Product descriptionProduct description
Product description
The ST215 is a high precision stripping and twisting machine specially developed for stripping small diameter cables.
High quality machining together with high grade materials render the ST215 a robust production machine.
The ST215 is a true all-rounder; it masters the stripping of standard cables in short cycles also micro-coaxial cables
with the highest precision. The absence of gripper jaws enables the ST215 to process the shortest of cable ends,
crushing of the sheath being also ruled out. The patented 4
44
4-
--
-blade
bladeblade
blade system
systemsystem
system permits the stripping of cable ends with total
and repeatable accuracy.
The sheath is removed by a rotary incision with subsequent pulling-off in a single operation. The ST215 can be
steplessly set to a different diameter or length in seconds by means of a scale.
System overview:
• Rotary incision
• Stripping head with a 4 blade system in one plane
• Knife changing performed without tools
• Stepless setting of diameter and length by means of a scale
The ST215 is intended exclusively for stripping copper conductors. Take care to ensure that no metal objects
(e.g. screwdrivers, tweezers) come into contact with the blades where they can cause damage.
Centering d
Centering dCentering d
Centering device (Optional)
evice (Optional)evice (Optional)
evice (Optional)
The purpose of the steplessly adjustable centering is to ensure that the cable is aligned accurately with the centre of
the blades. If your ST215 has been delivered without a centering device, this can be retrofitted without problems.
The advantages of the centering device are as follows:
• Influencing of the stripping quality by the user is practically ruled out.
• The stripping diameter can be set very close to the conductor, enabling very thin walled insulations to be stripped
without problem.
