Placing
Placing Placing
Placing in
in in
in operation
operationoperation
operation
The order of the settings must be observed because due to the construction, any changes to the stripping
diameter will render it necessary to make adjustments to the stripping length!
The protective cover must be removed for settings to the stripping head, i.e. the centering device or the stripping
diameter. This can be removed or refitted by simply pulling out or pushing in. The protective cover must be pushed right
up to the front panel; remove any scraps of cable between the cover and the front panel.
For safety reasons the machine cannot be started without the protective cover in place!
The blue LED will blink 3 times if the cover is not mounted and you try to start the stripping cycle.
Setting the
Setting the Setting the
Setting the centering
centering centering
centering device
devicedevice
device
• Measure the external diameter, e.g. with the slide gauge or centering device open; introduce the cable and
close the centering device.
• The cable must in no event be clamped but should be movable in the centering device without play.
Special regulations, (e.g. military) stipulate blocking of the centering device. This can be carried out with the light
Allen screw, using the Allen key supplied.
No not confuse the light Allen screw with the black one. If you should slacken the black Allen screw, the
centering device will be displaced and will have to be recalibrated.
Setting the
Setting the Setting the
Setting the D
DD
Diameter
iameteriameter
iameter
• Evaluate the cable conductor diameter, e.g. with the sliding gauge.
• Check that the Wayback is set to 0 (ST215W only).
• Then set a somewhat large value at the diameter scale (ca.
(ca. (ca.
(ca. + 0.1mm
+ 0.1mm+ 0.1mm
+ 0.1mm or 0.01 Inch
or 0.01 Inchor 0.01 Inch
or 0.01 Inch)
))
). The diameter scale is
graduated in 0.01mm
0.01mm0.01mm
0.01mm (0.001 Inch)
(0.001 Inch)(0.001 Inch)
(0.001 Inch).
When setting the diameter, always turn from a larger diameter to the desired value. For example; if the existing
setting is 0.95mm and you wish to set 1.00mm, first open to ca. 1.50mm and then turn to 1.00mm.
If the stripping diameter is set too small, the blades will cut into the conductor and a high pulling force will be
required to pull off the insulation. This can damage the blades.
• If required, the diameter adjustment can be blocked with the supplied grub screw. Remove the existing grub
screw at the side of the diameter adjustment using the Allen key supplied, and carefully screw in the longer
grub screw as far as the stop.
