Fig. 4
Adjust
machine
Insert the cable end to the sensor
With
foot
pedal
Without foot pedal
When the cable touches the
activation sensor, the machine will
automatically start the stripping
cycle.
Start the stripping cycle with the
foot pedal
Full strip?
No
Yes
Wait until the stripping head
stops before pulling out the
cable
Wait until the
LED is on or the
solenoid air valve is activated (you
hear the air blowing out the air
nozzle). Now pull out the cable
while the LED is on
!
End of
st
ripping
cycle
Twisting
?
(ST215W
only
)
No
Cleaning
cycle
(starts automatically)
Yes
